USE MANUAL
MINISENTRY-2
124 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S, BP249, ZI de Vauzelles, 3760
2
Loches Cedex
: The device must be connected to the electrical mains on a grounded power supply and with a
3-conductor cable of 1 mm
2
.
7. Power up the unit and go to the start-up screen.
26 ASEMBLY GUIDE, VEHICLE CONFIGURATION
26.1 PEDESTRIAN KIT
Item Description
1 Footplate for each post with flat washers and wing nuts
2 Primary detector post with MiniSentry 2 Monitor
3 Top cross piece with attached elbows for pedestrian configuration
4 Secondary detector post
5 End caps (x2) for vehicle configuration needs and shipping
6 Power supply cable
ON / OFF
Switch
Upon powering up the MiniSentry,
the
above start-up screen will
appear
after a few seconds.
