Mirion Technologies MiniSentry-2 - Charging Indicator

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S., BP249, ZI de Vauzelles, 37602
Loches Cedex
19 / 170
Keys Bottom screen Function
Increment a level
Move the selection to the right
Export Log files
Save a data
Start a measurement
Navigation down arrow
Decrease Value (In value edition)
Decrease a value
Arrow up navigation
Increment Value (In Value Edition)
Increment a value
8.3.3 Charging indicator
The indicator lights up green orange or red to indicate the status of the batteries and power supply:
External power
supply 110 - 240
Vac
Optional External Internal Li-Ion Charging LED indicator
Plugged - -
Not plugged > 25% -
pulse
Not plugged >5% and <25% -
pulse
Not plugged <5% -
pulse
Not plugged
Not present or
flat
Low bat
Blink
