18.3.2 Digital input/output
Default operating table of MiniSentry-2 relays.
RL1
RL2
RL3
RL4
RL5
byte
Digital input 0 0 0 0 0
MSB
Unacknowledged fault 0 0 0 0 0
Unacknowledged alarm 0 0 0 0 0
MiniSentry-2 fault 0 0 0 0 1
Interface 2
Probe fault 0 0 0 0
1
Channel 2
Measure 0 0 0 0 0
Saturation 0 0 0 1 0
Alarm 0 0 0 1 0
Alert 0 0 0 1 0
Channel 1
Measure 0 0 0 0 0
Saturation 0 0 1 0 0
Alarm 0 0 1 0 0
Alert 0 0 1 0 0
Interface 1
Probe fault 0 0 0 0
1
Channel 2
Measure 0 0 0 0 0
Saturation 0 1 0 0 0
Alarm 0 1 0 0 0
Alert 0 1 0 0 0
Channel 1
Measure 0 0 0 0 0
Saturation 1 0 0 0 0
Alarm 1 0 0 0 0
Alert 1 0 0 0 0
LSB
Setting table of fault relays of MiniSentry-2
« DeviceSettings. cfg » file
Relays
MSB LSB
Decimal value
Parameter
RL1
0000000000000000000111 7
rl1signalcondition
RL2
0000000000000001110000
112
rl2signalcondition
RL3
0000000000111000000000
3584
rl3signalcondition
RL4
0000001110000000000000 57344
rl4signalcondition
RL5
0001100000000100000000
393472
rl5signalcondition
