8.3 MINISENTRY CONTROL UNIT
Figure 3 Controller module electronics
8.3.1 Front panel
Figure 4 MiniSentry-2 - Front panel
LCD display
Loud speaker
Keyboard
Portal detector LED status
FRISKER CSP
probe LED
status
Charging LED
Bottom panel
Front panel
Clamps
Red / green light tower
(Optional)
