USE MANUAL
MINISENTRY-2
114 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S, BP249, ZI de Vauzelles, 3760
2
Loches Cedex
19 CARACTERISTICS OF THE MONITOR
19.1 DECLARATION OF CONFORMITY
Electromagnetic compatibility: The MiniSentry-2 has successfully passed the electromagnetic
compatibility (EMC) tests according to the EU directive and 62244 standard
MiniSentry-2 comply with FEM-REP-21
Full declarations of conformity are available upon request to:
MIRION TECHNOLOGIES (Canberra) SAS
BP249
ZI de Vauzelles
37602 Loches CEDEX
FRANCE
19.2 MECHANICAL CHARACTERISTICS
− Assembled Dimensions (W x H x l): 2159 mm x 1118 mm x 452 mm (85 in x 44 in x 17.8 in)
− Weight: 42.5kg (93.7 lb)
19.3 ENVIRONMENTAL CHARACTERISTICS
Environmental characteristics
− Audible alarm: Greater than 92 dB (A) at 30 cm (11.81 in)
− Operating temperature: -25°C (-13°F) to + 55°C (131°F)
− Storage temperature: -25°C (-13°F) to + 60°C (140°F)
− Relative Humidity: Non-Condensing, up to 93%
− Weather resistant for outdoor operation in adverse weather conditions
− Max operating altitude: 2000 m (6,562 ft)
− Pollution Degree (CEI 60664-1): 2
− Surge category: II
19.4 ELECTRICAL CHARACTERISTICS
− Power supply
• DC power supply output: 12VDC, 500 mA
• AC power supply input:
 CEE 7/7 Plug and IEC 320 C13 socket
 100-240V 50/60 Hz, 500 mA
 MAINS supply voltage fluctuations up to ±10 % of the nominal voltage
 Protection: 2 fuses (5 x 20 mm, 1A, T type glass, UL standard)
− Inputs/Outputs :
• 5 relay outputs: NO, NC, 125 VAC, 60 VDC, 1A contacts
• 2 opto-coupled inputs: control voltage between 5VDC and 24VDC
• RS485 link: 2-wire MOD BUS
• +5 V output; 150 mA
• +24 V Input; 500 mA
