PROTOCOL-SPECIFIC INFORMATION
262
Table 60: EtherCAT Default User Configurable I/O Process Data Format
Consumed Data
(Master to Inverter)
Produced Data
(Inverter to Master)
Word Offset
Inverter Register
Word Offset
Inverter Register
0
1
0
100
1
2
1
102
:
None
:
None
Description
This 32-character (max) field is strictly for user reference: it is not used at any time by the driver.
Register
The inverter register as described in section 4. For the Transmit Data Word object, enter a “status”
register to be monitored. For the Receive Data Word object, enter a “command” register that can be
written.
Data Type
Each data word is fixed to 16-Bit Unsigned. This is equivalent to two bytes. The data word is transferred
in big endian format.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
