Mitsubishi 700 Series User Manual

MITSUBISHI CONFIGURATION STUDIO
77
5
Current Status
Indicates the status of the most-recently received
packet. This field is updated each time the “RX
Counter” or “RX Error Counter” increments. Refer to
Table 24 for a list of supported codes.
Last Error
Indicates the last reception error that occurred. This
field is updated each time the “RX Error Counter”
increments. Refer to Table 24 for a list of supported
codes.
5.10 Help
For assistance in understanding configuration
objects and fields, simply hover the mouse over the
object or text to display a useful tooltip. Ensure that
the Help…Show Help Tooltips option is checked.
Links to videos and documents can be found in the
Help menu. Please review the tooltips and links
before contacting technical support for more in-depth
assistance.
Table 24: Diagnostic Codes
Diagnostic Code
(Hex)
Description
0x00
No Error
0xE0
No Connection
0xF0
Invalid Data Address
0xF1
Data Error
0xF2
Write To Read-Only
0xF3
Read From Write-Only
0xF4
Target Busy
0xF5
Target Error
0xF6
Cannot Execute
0xF7
Mode Error
0xF8
Other Error
0xF9
Memory Error
0xFA
Receive Error
0xFB
Invalid Function
0xFC
Invalid Packet
0xFD
Security Error
0xFE
Checksum Error
0xFF
Timeout Error

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
