Mitsubishi 700 Series User Manual

PROTOCOL-SPECIFIC INFORMATION
206
• The 3E/4E Device Memory Random Write command will attempt to write to all requested device
points even if an error is encountered. Ensure that all requested device points are valid before using
Device Memory Random Write.
• The driver can be configured to detect a timeout (communication loss) and perform a timeout action.
9.5.2 Read/Write Commands
If applicable, the network number is 0, the PC number (node number) is 0xFF, the module I/O number
(process number) is 0x3FF, and the module station number is 0.
Table 45 lists the supported commands. Device read/write commands only support 16-bit word access.
Table 45: MELSEC / SLMP Server Commands
Frame
Type
Command
Name
Command
Code
Subcommand
Code
Max
Points
3E/4E
CPU Model Read
0x0101
0x0000
-
3E/4E
Node Search
0x0E30
0x0000
-
3E/4E
IP Address Set
0x0E31
0x0000
-
3E/4E
Device Info Compare
0x0E32
0x0000
-
3E/4E
Status Read
0x0E44
0x0000
-
3E/4E
Communication Setting Get
0x0E45
0x0000
-
3E/4E
Device Memory Batch Read
0x0401
0x0000
724 (3E) / 722 (4E)
3E/4E
Device Memory Batch Write
0x1401
0x0000
719 (3E) / 717 (4E)
3E/4E
Device Memory Random Read
0x0403
0x0000
360 (3E) / 359 (4E)

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
