6.4 Customizing the Embedded Web Server
6.4.1 Customization Overview
It is possible for end-users to customize the embedded web server in order to create their own
application-specific or corporate “look and feel”. Knowledge of authoring dynamic web content is
required. Using windows explorer, it is possible to load customized web server content into the “WEB”
folder on the interface card’s file system (refer to section 7.2). Usually, this web server content contains
programming which implements the XML socket-based XTPro protocol (refer to section 6.4.2). Via
XTPro, the embedded web server can gain access to any inverter register and the interface card file
system resources, and manipulate them as required.
Notes
• All files in the “WEB” folder may be deleted or replaced if desired by the user.
• The default HTML file targeted by the web server is “index.htm”. Therefore, when customizing the
web server content, ensure that initial file “index.htm” exists.
• All files accessed by the web server itself must reside in the “WEB” folder. Note that this does not
restrict active web server content to using only the “WEB” folder, however, as XTPro “read_file” and
“write_file” commands can access any existing location on the file system.
• If the factory-default “WEB” folder contents need to be recovered (if they are accidentally deleted,
for example), they can be downloaded from the product web page
on the internet.
• Two simultaneous web server sessions are supported. Note that the number of available
simultaneous web server sessions is independent of the number of available simultaneous XTPro
XML sockets.
