PROTOCOL-SPECIFIC INFORMATION
9.10 IEC 61850 Server
9.10.1 Overview
The IEC 61850 server driver allows an IEC 61850 client to interact with the interface card via GGIO
(generic process I/O) objects, unbuffered reports and GOOSE messages. The GGIO process data is
entirely user-configurable. The unbuffered report control block can be configured with any IEC 61850
configuration tool. The GOOSE communication parameters are also user-configurable.
Some other notes of interest are:
• The ICD file can be obtained from the included CD-ROM or downloaded from the product web page
on the internet.
• The CID file is generated by the studio. In the studio, navigate to File…Generate File…Generate
IEC 61850 CID File.
9.10.2 Server Settings
In the studio, navigate to A7NETH-2P…Ethernet…IEC 61850 Server.
IED Name
The IED name is used for identification of this device on the IEC 61850 network. Enter a string between
1 and 32 characters in length.
