PROTOCOL-SPECIFIC INFORMATION
257
9
Subnetwork Name
The name of the station "subnetwork" on which this device resides but it is not relevant to the operation
of this device. This name is only meaningful for SCD files and is used when merging CID files to build a
substation-wide SCD file.
TCP Port
The TCP listening port for accepting connections and receiving requests.
Authentication
Enable or disable password authentication. If authentication is enabled, the client must provide a valid
password when attempting to connect to this device. The password is defined in section 5.3.1.
9.10.3 GOOSE Communication Parameters
In the studio’s Project panel, navigate to A7NETH-2P …Ethernet…IEC 61850 Server. The following
configuration options will determine the values used in the GOOSE message.
Priority
802.1Q priority level encoded in the Ethernet frame as the Priority Code Point (PCP) that can be used
for QoS.
VLAN ID
802.1Q virtual LAN (VLAN) ID that can be used in a VLAN-aware network.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
