Mitsubishi 700 Series User Manual

PROTOCOL-SPECIFIC INFORMATION
248
9.9.7.6 Online Device Discovery and Configuration
In the Project tree, expand plc1…Distributed I/O…PROFINET IO-System (100):PN/IE_1. Expand the
device and double-click Online & diagnostics. In the next panel, expand Functions and select the
Assign IP address node. Click the Accessible devices button. Select the appropriate PG/PC
interface and click the Start search button to discover and display the PROFINET devices on the
network as shown in Figure 88. Select the device and click the Apply button.
Figure 88: Discover PROFINET Devices on the Network

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
