PROTOCOL-SPECIFIC INFORMATION
222
9.8.4 Remote Device Settings
In the studio’s Project panel, navigate to A7NETH-2P…Ethernet… SLMP Client…Remote Device.
Name
This 32-character (max) field is strictly for user reference: it is not used at any time by the driver.
IP Address
Defines the destination IP address. This is the IP address of the targeted remote server device.
Transport Type
Select TCP or UDP.
TCP Port
This field is only enabled only if the Transport Type is set to TCP. Defines the destination TCP port
(1…65535). This is the “listening” port on the server.
UDP Port
This field is only enabled only if the Transport Type is set to UDP. Defines the destination UDP port
(1…65535). This is the “listening” port on the server. This also defines the local source port. Ensure that
this port assignment is unique, and does not conflict with ports utilized by other drivers.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
