Mitsubishi 700 Series User Manual

PROTOCOL-SPECIFIC INFORMATION
138
9.2.11.2 ControlLogix Example: EDS Add-On Profile (AOP) AC/DC Drive Profile
This section will demonstrate how to configure the EtherNet/IP AC/DC drive profile I/O connection.
1) Complete all steps in section 9.2.11.
2) Locate the interface card in the 1756-ENBT/A branch under the “I/O Configuration” in the controller
organizer view. Right click on the interface card, choose “Properties”, and select the “General” tab.
3) Configure the AC/DC Drive Profile connection. Refer to Figure 39.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
