Mitsubishi 700 Series User Manual

EMBEDDED WEB SERVER
92
6.3.4 Submitting Changes
Whenever any of the gauge window configuration items in
the Dashboard Tab have been changed, the “submit”
button located on the right-hand portion of the web page
must be selected in order to write these settings to the
interface card’s filesystem. Refer to Figure 23. Note that
submitting the Dashboard Tab configuration does not
require rebooting of the interface card: the changes take
effect immediately, and the interface card continues its
operation without interruption.
Figure 23: Submit Dashboard Changes

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
