EMBEDDED WEB SERVER
78
6 EMBEDDED WEB SERVER
6.1 Overview
The interface contains an embedded (HTTP) web server, which allows users to access the inverter’s
internal data in a graphical manner with web browsers such as Microsoft Internet Explorer or Mozilla
Firefox. In this way, the inverter can be monitored and controlled from across the room or from across
the globe. To access an interface’s embedded web server, directly enter the target unit’s IP address into
the address (URL) field of your web browser. Refer to Figure 7 for a representative screenshot of the
web server interface. In order to access the web server and view the parameter values, destination TCP
ports 80 and 843 must be accessible from the client computer.
Note that in order to view the interface’s web page, the free Adobe Flash Player browser plug-in is
required. The plug-in can be downloaded from http://www.adobe.com
.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
