Mitsubishi 700 Series User Manual

PROTOCOL-SPECIFIC INFORMATION
196
Units
Select the desired units from this dropdown menu. If the desired units are not available in the dropdown
menu, select “Other Units” and enter the appropriate enumerated value (as defined by the BACnet
Specification) in the “Unit Value” field.
Unit Value
This field is enabled only when the “Units” selection is set to “Other Units”. Enter the appropriate
enumerated value (as defined by the BACnet Specification.)
Relinquish Default
Defines the default value to be used for an object’s present value property when all entries in the
object’s priority array are NULL.
9.4.7.3 Analog Value Object Settings
Object Name
The name of the BACnet object. Enter a string of between 1 and 32 characters in length. All object
names must be unique within a node.
Instance
The BACnet object’s instance number. Enter a value between 0…4194302 (0x0…0x3FFFFE).
Register
The inverter register number (refer to section 4) that the BACnet object’s present value will access.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
