MITSUBISHI CONFIGURATION STUDIO
76
5.8 Restore Factory Settings
The interface card (connected via USB) can be restored to the factory settings. Note that the filesystem
will be reformatted, which will destroy all custom modifications and configurations. Please backup the
configuration before executing this feature. The factory settings can be restored by:
• Right-clicking on the device in the Project panel and choosing Restore Factory Settings.
• Selecting the device in the Project panel and navigating to Restore Factory Settings.
5.9 Diagnostic Object
Diagnostic objects are optional and can only be added to specific protocol objects.
TX Counter
A 32-bit counter that increments when the driver transmits a packet.
RX Counter
A 32-bit counter that increments when the driver receives a valid packet.
RX Error Counter
A 32-bit counter that increments when the driver receives an error response packet, or when an error
occurs upon reception of a packet.

Mitsubishi 700 Series Specifications

General

Control Method	Vector Control
Overload Capacity	150% of rated current for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication Options	RS-485, Profibus, Ethernet
Output Power Range	0.4 kW to 630 kW
Cooling Method	Forced air cooling (fan) (Varies by model)
Operating Temperature	-10 to +50°C (Varies by model, may be derated at higher temperatures)
Storage Temperature	-20 to +65°C
Humidity	95% RH or less (non-condensing)
Altitude	Up to 1000 m above sea level (Derating may be required above 1000 m)
Enclosure Rating	IP20
Model	FR-A700, FR-F700, FR-E700, FR-D700, FR-S700
