PROTOCOL-SPECIFIC INFORMATION
“None”..................................... No effect. The inverter will continue to operate with the last available
settings.
“Apply Fail-safe Values” ......... Apply the fail-safe values as described in section 5.4.1.
9.6.3 Produced and Consumed Data Settings
In the studio’s Project panel, add A7NETH-2P…Ethernet…CC-Link IE Field Basic Server
…Produced I/O Data…Produced Data Word and/or Consumed I/O Data…Consumed Data Word.
The Produced Data Word objects defines the structure of cyclic RWr status words sent from the inverter
back to the controller. The Consumed Data Word objects will define the structure of the cyclic RWw
command words sent from the CC-Link IE Field Basic controller to the inverter. These objects allow the
creation of custom-built I/O data. Up to 32 “command” register values can be sent to the inverter, and up
to 32 “status” register values can be sent back to the controller. Therefore, up to 32 Produced and 32
Consumed Data Word objects can be created. If a consumed word offset is not defined, that data will be
ignored by the inverter. If a produce word offset is not defined, the value will default to 0. The I/O data
format is summarized in Table 47.
Description
This 32-character (max) field is strictly for user reference: it is not used at any time by the driver.
Produced Data Word Offset
The value from the associated inverter register will populate this word offset of the produced data that is
to be sent to the client. It is recommend to start at word offset 0.
