PROTOCOL-SPECIFIC INFORMATION
Consumed Data Word Offset
The consumed data received from the client at this word offset will contain the value to be written to the
associated inverter register. It is recommend to start at word offset 0.
Register
The inverter register (refer to section 4) associated with the word offset. For the Produced Data Word
object, enter a “status” register to be monitored. For the Consumed Data Word object, enter a
“command” register that can be written.
Data Type
Each data word is fixed to 16-Bit Unsigned. This is equivalent to two bytes.
Table 47: CC-Link IE Field Basic User-Configurable I/O Data Format
Consumed Data
(PLC to Inverter)
Produced Data
(Inverter to PLC)
