4. Service Procedures - Replace Components - Creaser Module
150 Morgana DocuMaster MFC - Service Manual
4.10.2.1 Remove the RH Side Plate
Set screw behind the operating
lever
Operating Lever Assembly
Roller Pressure Spring
Figure 4.152 RH Creaser Side Plate
The operating lever assembly is
removed from the input roller
Figure 4.153 RH Side Plate Screws
Figure 4.154 LH Side Plate Screws
Tools:
• Allen Key: 2.5mm, 3mm, 4mm, 6mm
• Screwdriver: Pozidriv No. 2
• Gear Puller.
To Next Page
