4. Service Procedures - Replace Components - Gathering Area
170 Morgana DocuMaster MFC - Service Manual
4.11.4 Replace the Ioniser Bar
Ioniser Bar Cable
Cable Tie
Figure 4.182 The Ioniser Bar Power Cable
LH Mounting Bracket
RH Mounting Bracket
Ioniser Bar
A4 Pinch Drive
Figure 4.183 The Ioniser Bar
Mounting Bolt and Nut
Bracket screws
Figure 4.184 LH Ioniser Bar Mounting Bracket
Tools:
• Allen Key: 3mm
• Screwdriver: Right-angle Pozidriv No. 1
• Spanner: 7mm, 2 x 15mm
• Pliers: Side Cutters.
