7. Electrical and Control System - Low Voltage Transformer Tappings
216 Morgana DocuMaster MFC - Service Manual
207V – 216V Input = (187V – 220V range) = 200V Tap
• The measured voltage = 216V
• The usual local input voltage = 210V – 254V
• Use transformer tap position = 200V
7.2.2 Low Voltage Transformer Output
The, low voltage AC output cable from the low voltage transformer, connects to PL1 on
the interface PCB in the DRV module. The table that follows shows the nominal output
voltages of the transformer.
Low Voltage Output
Wire Pair Voltage (VAC)
White 9.0V
Orange 21.0V
