8. Installation Manual - Unpack the MFC
254 Morgana DocuMaster MFC - Service Manual
8.2.2 Install the Adjustable Feet

Caution: It is dangerous to move the MFC when the adjustable feet are removed.
Always install the adjustable feet before you st
art to move the MFC or it will be
unstable and can be damaged.

Warning: The MFC is heavy. It is necessary for two people to install the adjustable
feet. Always follow good health and safety procedures when
you lift.
Tools:

• Screwdriver: Pozidriv No. 2
• Spanner: 12mm.
Step Action Information
1 Make sure that the locking nut is
inst
alled against the adjustment
nut on each adjustable foot.
2 Put the MFC at an angle to give
access
to the foot mounting
bracket.
3 Install the adjustable foot on the
foot mounting
bracket.
Turn the adjustable foot fully into the
foot bracket.
4 Do Steps 2 thru 3 to install the
second adjust
able foot.
8.2.3 Remove the Transport Brackets
The transport brackets are necessary to hold the MFC to the MFC shipping pallet. You
must remove the transport brackets before you install the MFC.
Tools:

• Allen Key: 3mm.
Step Action Information
1 Remove the screws that attach the
transport bracket to
the MFC.
Hold the bracket when you remove
the last screw.
2 Remove the transport bracket.
3 Install the screws that you
removed back into
the feed bin
side plates.
4 Do Steps 1 thru 3 to remove all the
transport bracket
s.
