8. Installation Manual - Install the MFC
256 Morgana DocuMaster MFC - Service Manual
8.3.5 Turn on the Booklet-Maker System
Step Action Information
1 Set the BMP main input switch to
the
ON (I) position.
The BMP will beep one time and then
beep twice when it is ready.
2 Set the ASM main input switch to
the
ON (I) position.
The ASM motor will start for several
seconds and then stop.
Caution: Do not put any books
in to
the ASM until the motor has stopped.
3 Move the BMP, TMP and ASM
towards
the MFC until the BMP is
stopped by the gathering area.
8.3.6 Turn on the MFC
Step Action Information
1 Connect the MFC to the mains
power supply
.
• 230V: connect the mains lead to
the input plug on the CAP.
• 115V: connect the mains leads to
the input plug on the CAP and
the input plug on the DRV.
2 Set the MFC main input switch to
the
ON (I) position.
• Make sure that the E-stop switch
is not pushed in.
The GUI panel will show the
BASIC
setting page when the MFC is ready.
4 Connect the BMP to the TMP. (See the MFC User
Operating
Instructions Manual).
5 Connect the ASM to the mains
power supply
.
Connect the mains lead to the input
plug at the front of the ASM.
6 Connect the ASM interface lead to
the TMP
.
Step Action Information
