4 Handling the printer VJ-1624 OPERATION MANUAL
4-16
5. After installing the media holder plates, make sure that they do not interfere with the media as it is
fed through the printer.
CAUTION
• If a media jams when using the media holder plates, the plates may be deformed.
When the media holder plates are deformed,
• Do not remove the clogged media by force.
• Stop using the printer.
Using the printer with deformed media plates may damage the grid roller or print
heads.
Contact your local MUTOH dealer.
NOTE
• If there is interference with the media as it is fed through the printer after the media holder plates
have been installed, the media holder plates should not be used.
6. If the plates are not used, return the plates to their initial positions as shown in the following figure.
No. Name
1 Roll media
2 Media holder plate
3 Media loading position
4 Platen
1
1
4
3
2
1
4
2
3
