6-24 Installing and Using Utilities

Startup

IMPORTANT:

 Do not turn off the DC power during while updating the BMC Firmware.

 The updated BMC firmware becomes valid after restarting the system.

Windows Server 2003

Select [All Programs] → [BmcOnlineUpdate] → [BmcOnlineUpdate].

Windows 2000

Click [Programs] → [BmcOnlineUpdate] → [BmcOnlineUpdate].
