Internal Cabling Diagrams 10-9
POWER CABLES
An example of the power cable connection is shown in the figure below. The server only uses the power cables shown
here.
[Standard configuration]
îš„ SATA
CD-ROM drive
Floppy disk drive
Power
supply
Mother board
Power cable
Option device
P2
P1
Option device
P3
P4
P5
P6
P10
P11
P12
P13
îš„ SCSI
CD-ROM drive
Floppy disk drive
Power
supply
Mother board
Power cable
Option device
P2
P1
Option device
P3
P4
P5
P6
P10
P11
P12
P13
