General Description 2-21
When you fail to eject:
When you fail to eject the CD-ROM tray with the Open/Close button, follow the procedure below.
1. Press the POWER switch to power off the server. (The POWER/SLEEP lamp goes off.)
2. Insert a metal pin of approximately 1.2 mm in diameter and 100 mm in length (a straightened large paper clip
will make a substitute) into the emergency hole on the right front of the CD-ROM drive and gently push it in
until the tray is ejected.
Emergency hole
IMPORTANT:
îš„ Do not use a toothpick or plastic stick that is easy to break.
îš„ If this procedure does not let you take out the CD-ROM, contact your service
representative.
3. Hold the tray and pull it out.
4. Take out the CD-ROM.
5. Push the tray back into position.
