8-10 Troubleshooting
Beep Codes
If an error occurs during the POST, the server beeps, indicating the type of error.
Each number indicates the number of short beeps, and a hyphen indicates a pause. For example, the beep interval
1-2-2-3 indicates 1 beep, pause, 2 beeps, pause, 2 beeps, pause, and 3 beeps notifying that the checksum error occurred
on ROM.
Beep code Description Recommended action
1-2
Option ROM initialization
error
1. Check if the setting with SETUP is correct.
2. Check if the optional add-in card is properly
installed if the Option ROM expansion of the
additionally installed add-in card is not displayed.
3. Ask your service representative to replace the
add-in card or mother board.
3-3
1-2-2-3
ROM checksum error Replace the mother board.
1-3-1-1 DRAM refresh test error 1. Check if the DIMM is properly installed.
2. Remove the DIMM once, and then re-install it to
check if it operates normally.
3. Ask your service representative to replace the failed
DIMM or mother board.
1-3-1-3 Keyboard controller error 1. Check if the keyboard is properly connected.
2. Replace the mother board.
1-3-3-1
No memory or capacity
check error
1-3-4-1 DRAM address error
1-3-4-3
DRAM test Low Byte
error
1-4-1-1
DRAM test High Byte
error
1. Check if the DIMM is properly installed.
2. Remove the DIMM once, and then re-install it to
check if it operates normally.
3. Ask your service representative to replace the failed
DIMM or mother board.
1-5-1-1 CPU startup error 1. Check if the CPU is properly installed.
2. Remove the CPU once, and then re-install it to
check if it operates normally.
3. Ask your service representative to replace the
failed CPU.
2-1-2-3
BIOS ROM copyright test
error
2-2-3-1
Unexpected interrupt test
error
Replace the mother board.
To Next Page
