9-38 Upgrading Your Server
Additional HDD Cage
CAUTION
The qualified service representative can only install or remove the components
described in this subsection. To avoid personal injury or electrical shock, contact
your service representative when your need to install/remove the internal
components.
The additional HDD cage (called HDD cage) is dedicated to the server. It can contain four SATA hard disk drives to
configure a disk array. The hard disk drives can be removed or replaced with the server being powered on (hot-swap
feature).
Installation
Install the HDD cage in the following procedure.
1. See the section "Preparing for Installation and Removal" described earlier to prepare.
2. Remove the left side cover and front mask.
3. Disconnect the interface cable and power cord from the hard disk drive if connected.
4. Remove two screws on the front panel securing the hard disk drive bay.
To Next Page
