9-8 Upgrading Your Server
Front Mask
The front mask must be removed to install or remove the hard disk drive and 5.25-inch device.
CAUTION
The qualified service representative can only install or remove the components
described in this subsection. To avoid personal injury or electrical shock, contact
your service representative when your need to install/remove the internal
components.
Removal
Follow the procedure below to remove the front mask.
1. See the section "Preparing for Installation and Removal" described earlier to prepare.
2. Remove the left side cover as described earlier in this chapter.
3. Pull the release tabs (4) at the left end of the front mask toward you so that the tabs are removed from the
frame of the server.
IMPORTANT: If the tabs are pulled out toward you excessively, the hooks fixing the
right end of the front mask will be damaged. Only pull out the tabs a little.
