Appendix A
Specifications
Item 110Ej
Type Intel® Pentium® 4 processor Intel® Pentium® D processor CPU
Number of processors 1
Chipset Intel E7230
Standard 512 MB (512 MB × 1)
Maximum 8 GB (2 GB × 4, the standard DIMM must be replaced.)
Expansion unit 1 DIMM (512MB/1GB/2GB)
Expansion times 3 times
Memory module
SDRAM DIMM (DDR2-533, Unbuffered type, Dual channel memory
configuration supported)
Memory
Error check ECC
Graphics (VRAM) ATI ES1000 +16MB
Floppy disk (standard) 3.5-inch drive × 1 (standard)
Hard disk (standard) None
Hard disk (maximum) Internal:
For onboard S-ATA channel HDD x 4
For add-in SCSI card HDD x 4
Hot-plug:
SCSI HDD x 3
STAT1/SATA2 x 4
Auxiliary
input device
CD-ROM (standard) ATAPI interface × 1 (x40 speed)
5.25-inch file bay 3 slots (An ATAPI CD-ROM drive is factory-installed.)
3.5-inch disk bay 1 slot (A 1.44MB-floppy disk drive is factory-installed.)
Additional PCI slot
5 slots (1 slot for PCI-Express (x8), 1 slot for PCI Express (x1), 2 slots for
64bit/133MHz, 1 slot for 32bit/33MHz)
Disk array Standard (SATA controller)/Option (SCSI RAID controller)
Keyboard MINI DIN 6-pin connector (1 port)
Mouse MINI DIN 6-pin connector (1 port)
USB 4-pin (4 ports), USB 2.0 is supported
Serial D-sub 9-pin (1 port)
Parallel IEEE1284 standard, D-sub 25-pin (1 port)
Network RJ-45 (1 port, 1000BASE-T/100BASE-TX/10BASE-T)
External
interface
*1
Display MINI D-sub 15-pin (1 port)
Cabinet design Desk-side, mini tower
External dimensions 309
*1
(width) × 440 (height) × 518 (depth) mm
Weight 19 kg (Max.)
Power supply 100 to 120 VAC ±10%, 200 to 240 VAC ±10%, 50/60 Hz ±1 Hz
Power consumption 380 W
Temperature 10 to 35°C (operating), -10 to 55°C (non-operating, storage)
Environmental
requirements
Humidity 20 to 80% RH (no condensation)
*1 When stabilizers are installed. 198 mm when stabilizers are enclosed.
