Configuring Your Server 4-5
Configuration Examples
The following describes examples of configuration required to use software-link features or for system operations.
Time and Date Settings
You can also change the time and date settings via the operating system commands.
Select [Main] - [System Time].
Select [Main] - [System Date].
Link with Management Software
To control power supply of the server with ESMPRO Manager via the network
Select [Advanced] - [Advanced Chipset Control] - [Wake On LAN/PME] - [Enabled].
Select [Server] - [AC LINK] - [Stay Off].
ATA Drive Settings
To check the ATA drives connected with the onboard ATA channels.
Select [Main] - [Primary IDE Master], [Primary IDE Slave], [IDE Secondary/Master], and [IDE
Secondary/Slave].
To configure the RAID drive.
Select [Advanced] - [I/O Device Configuration] - [SATA Controller Mode Option] - [Enhanced]. Then select
[Advanced] - [I/O Device Configuration] - [SATA RAID Enabled] - [Enabled], and use the RAID
configuration utility (see "RAID Configuration Utility" in this chapter).
IMPORTANT: Be sure to set this parameter to [Enabled] after executing [Load Setup
Defaults] or CMOS clear. Leaving this parameter at the factory-set value (Disabled) may
destroy the data in hard disk drive.
UPS
To link power supply with the UPS
îš„ To power on the server when power is supply from the UPS
Select [Server] - [AC LINK] - [Power On].
îš„ To keep the server off-powered even when power is supplied from the UPS
Select [Server] - [AC LINK] - [Stay Off].
To Next Page
