4-6 Configuring Your Server
Boot
To change the boot order of devices connected to the server
Select [Boot] and specify the boot order.
To display POST check results
Select [Advanced] - [Boot-time Diagnostic Screen] - [Enabled].
You can also press
Esc while the full-screen logo is displayed to see POST check results.
To control from the remote console
Select [Server] - [Console Redirection] and set each item.
Memory
To check the installed memory (DIMM board) status
Select [Advanced] - [Memory Configuration] and check the status indications.
The on-screen DIMM group numbers and socket locations on the mother board are associated as shown in the
following figure.
DIMM #1
DIMM #2
DIMM #3
DIMM #4
To clear the memory (DIMM board) error information
Select [Advanced] - [Memory Configuration] - [Memory Retest] - [Yes] and reboot.
To run power-on memory test
Select [Advanced] - [Memory Configuration] - [Extended RAM Step] - [1MB] and reboot.
