NEC Express5800 110Ej User Manual

10-6 Internal Cabling Diagrams
Fourth hard disk drive
5.25-inch device bay
5
Third hard disk drive
SCSI ID2
Second hard disk
drive
3.
SCS
CD-ROM drive
Floppy disk drive
T
Power
supply
Mother board
Floppy disk
erminator
drive
IDE
IDE cable FDD cable S
LED
connector
Disk array
controller
[Optional file bay installed]
CSI cable
Power
supply
Hard disk drive
device expansion kit
CD-ROM drive
Floppy disk drive
Mother board
Floppy disk
drive
IDE
IDE cable FDD cable SCSI cable
LED
connector
SCSI
controller
Unused
Unused
Unused
Unused
1st hard disk drive
2nd hard disk drive
3rd hard disk drive
Connect the LED cable provided with the server to the LED connector on the mother board and the disk array controller
for indicating the hard disk drive access status.
You can check the disk status (disk error or rebuilding of disk array) through the disk array management utility, Power
Console Plus, coming with the disk array controller.

NEC Express5800 110Ej Specifications

General

Form Factor	Tower
RAM	Up to 32GB DDR3
Storage	SATA
RAID	RAID 0, 1
Network	Dual Gigabit Ethernet
Hard Drive	Up to 4 x 3.5" SATA HDD
