Data Interfaces M6100 Broadcast Satellite Modulator
11.6.5 TS over IP Input Interface
Configure the TsoIP input interface.
M6100> TS over IP >> Input Interface
The two data Ethernet inputs make it possible to create a redundant interface input. For more
information pleaser refer to DataEthernetLinkRedundancy.onpage112
The following table describes the possible input selection options.
Selection Description
None No input selection, the functional block is not active.
Data 1 The data arriving on the Data 1 input interface is inserted into the device.
Data 2 The data arriving on the Data 2 input interface is inserted into the device.
Data Bond The data arriving on the Data 1 or Data 2 input interface is inserted into the
device.
The bond interface is used to create the link redundancy.
Only one link is active at a time.
Any Data Data arriving on the Data 1 or Data 2 input interface is inserted into the
device. The difference with data bond is that both links are active at the
same time.
Source redundancy is always applied on TS over IP. Refer to section:
SourceRedundancy.onpage132
This implies that all packets coming from one source are accepted. When using Any
Data and the multicast traffic from the same source is present on Data1 and Data2,
this data will be aggregated resulting in a corrupt Transport Stream.
