Appendix B - Overview of the Used Technologies M6100 Broadcast Satellite Modulator
15.2.2 MODCOD Definitions S2 Extensions
S2 Extensions comprises 87 MODCODs, optimized for linear and non-linear channels. Although the
MODCODs might use the same code/name as in DVB-S2, they are not interchangeable.
For linear channel applications, Newtec Cy N.V. has developed specific modulation
schemes (constellation mappings).
The modulation schemes designed for linear channels are indicated with L.
For example: 16APSK-L 162/180
• QPSK 45/180
• QPSK 60/180
• QPSK 72/180
• QPSK 80/180
• QPSK 90/180
• QPSK 100/180
• QPSK 108/180
• QPSK 114/180
• QPSK 120/180
• QPSK 126/180
• QPSK 135/180
• QPSK 144/180
• QPSK 150/180
• QPSK 160/180
• QPSK 162/180
• 8PSK 80/180
• 8PSK 90/180
• 8PSK 100/180
• 8PSK 108/180
• 8PSK 114/180
• 8PSK 120/180
• 8PSK 126/180
• 8PSK 135/180
• 8PSK 144/180
• 8PSK 150/180
• 16APSK 80/180
• 16APSK 90/180
• 16APSK 100/180
• 16APSK 108/180
• 16APSK 114/180
• 16APSK 120/180
• 16APSK 126/180
• 16APSK 135/180
• 16APSK 144/180
• 16APSK 150/180
• 16APSK 160/180
• 32APSK 100/180
• 32APSK 108/180
• 32APSK 114/180
• 32APSK 120/180
• 32APSK 126/180
• 32APSK 135/180
• 32APSK 144/180
• 32APSK 150/180
• 32APSK 160/180
• 32APSK 162/180
