Features Descriptions M6100 Broadcast Satellite Modulator
12.1.9 Amplitude Slope Equaliser
M6100 >> Modulator >> Ampl Slope Equalizer
Configure the amplitude slope equalizer. An amplitude slope in the up-converter or in the high
power amplifier can be compensated by using this equalizer. The equalizer has a maximum range of
± 2 dB/50 MHz.The compensation can be set in the range between -7 and +7.
The slope equalizer can also be used to compensate for cable slope.
12.1.10 Rate Priority
M6100> Modulator >> DVB-S >> Rate Priority
Define the rate priority:
• Symbol Rate;
• Bit Rate.
12.1.11 Symbol Rate
Define the symbol rate in Mbaud.
This parameter can only be set if the setting Rate Priority = Symbol Rate.
M6100> Modulator > DVB-S >> Symbol Rate
12.1.12 Bit Rate
M6100> Modulator > DVB-S >> Bit Rate
Define the bit rate in bps (bits per second).
This parameter can only be set when the Rate Priority = Bit Rate.
