Features Descriptions M6100 Broadcast Satellite Modulator
12.1.16.5 Clock Output
M6100 >> Modulator >> Clock Output
Enables or disables the transmission of a 10MHz clock signal on the L-BAND output interface.
For the reference clock settings and characteristics, refer toReferenceClock.onpage106
12.1.16.6 Roll Off Signaling
M6100 >> Modulator >> Roll Off Signaling
• standard : (2 bits : "10") roll off signaling value is used for roll off = 20%;
• reserved : (2 bits: "11") roll-off signaling value is "reserved" (11) is used for roll off < 20%.
Some DVB-S2 receivers can use the received roll-off bits state '11' for selecting a 15% roll-off filter.
In this case, it is favorable to choose the setting "reserved".In all other cases, it is recommended to
use the setting "standard" as this will guarantee compatibility with DVB-S2 receiving equipment.
