Physical Description M6100 Broadcast Satellite Modulator
7.2.3 Craft Interface
The craft interface is a SUBD 9 pin connector interface that can be used to manage the device using
the command line interface (CLI). For more information please refer to section:
CommandLineInterface(CLI)onpage59
It is used to control the device over RS232.
The line settings for the craft interface are:
• Speed 115200 baud;
• Eight data bits;
• No parity bit;
• One stop bit.
Use the following pin connections to create a crossover cable between the M6100
Boadcast Satellite Modulator and the managing device.
Pin Name Function
1 Not connected
2 Rx-D Receive Data
3 Tx-D Transmit Data
4 Not connected
5 GND Shield ground
6 Not connected
7 Not connected
8 Not connected
9 Not connected
The following figure shows the craft interface connection.
