Appendix A - Alarm List M6100 Broadcast Satellite Modulator
14.4 ASI Alarms
Alarm Description
ASI IN General This alarm is raised when there is a general ASI
input alarm.
• ASI IN No Input Signal;
• ASI IN No Input Data;
• ASI IN Buffer Overflow;
• ASI IN Invalid TS Bit Rate.
ASI IN No Input Signal This alarm is raised when no input signal is
detected at the selected ASI input.
ASI IN Invalid TS Bit Rate This alarm is raised when the measured input
Transport-Stream (TS) bit rate is higher or lower
than the expected value.
ASI IN No Input Signal ASI This alarm is raised when no input signal is
detected at the corresponding ASI input.
ASI IN No Input Data This alarm is raised when no input data is detected
at the selected ASI input.
ASI IN Buffer Overflow This alarm is raised when the input data buffer is
full.
