Data Interfaces M6100 Broadcast Satellite Modulator
11.7.1 MPE Input Selection
M6100>MPE >> Input Selection
Configure the MPE input interface.
The two data Ethernet inputs make it possible to create a redundant interface input. Refer to section:
DataEthernetLinkRedundancy.onpage112
Selection Description
None No input selection, the functional block is not active.
Data 1 The data arriving on the Data 1 input interface is inserted into the device.
Data 2 The data arriving on the Data 2 input interface is inserted into the device.
Data Bond The data arriving on the Data 1 or Data 2 input interface is inserted into the
device.
The bond interface is used to create link redundancy.
