Data Interfaces M6100 Broadcast Satellite Modulator
M6100>MPE >> Enable MPE
Using MPE makes it possible to transmit data along with the video transport stream.
This data can contain for example: software image files for DTH set-top boxes,Multi Home Platform
information or general low bit rate data for distribution in private networks.
The encapsulator replaces null-packets in the TS with useful payload of data packets. This
optimizes the use of the available bandwidth by using opportunistic data insertion. The user just
needs to define the bitrate of the carrier to something matching both streams at maximum load.
The TS will automatically be rate-adapted to the carrier rate and the MPE is inserted in it.
This feature works with any MPE capable receiver or IRD.
Input bit rates on the MPE input upto 20 Mbps are supported.
It is possible to insert signaling and perform shaping on this data.
Refer to the following figure:
