Features Descriptions M6100 Broadcast Satellite Modulator
12.10.3 Set the DC BUC Power for L-Band Tx
M6100 > Modulator >> BUC Power on L Band TX
Parameter Value Description
Enable On/Off Enable or Disable the L-Band DC supply.
voltage 24V /
48V
Select the appropriate voltage for the equipment used in
combination with the DC supply.On the back panel the
corresponding LED is activated.
Note: It is not possible to change this value when
the DC supply is enabled.
Measured
Output
Voltage
Range
0V / 48V
Displays the actual voltage level on the L-band Tx interface.
Output
Current
Range
0A / 8A
Displays the actual current being delivered by the DC supply:
• When an overcurrent is detected the circuit protection
mechanism is triggered and disables the DC supply.
The protection mechanism monitors every 1s if the overload
(overcurrent) is removed. The overload alarm is active.
• When a short circuit is detected the circuit protection mechanism
is triggered and disables the DC supply.
The protection mechanism monitors every 5s if the short circuit is
removed.
The short circuit alarm is active.
