General Device Settings and Actions M6100 Broadcast Satellite Modulator
10.3.7 Export a Configuration
Use this to export a configuration file.
Depending on the management interface GUI or CLI the following is done:
– GUI: the file is downloaded by the browser;
– CLI: the file is available on the FTP server.
» Navigate to the Tasks Pane;
» Click Device;
» Click Configurations;
» Click the in front of the Config Name you want Export;
» Click Export to export the XML file to a default folder (GUI) or to the FTP server (CLI).
The exported file can be:
• Used as a backup file;
• Edited offline and reused on another device In this case,
– Make sure that the configured options and activated licences are the same on
both devices.
• Forwarded for debugging purposes.
