Appendix B - Overview of the Used Technologies M6100 Broadcast Satellite Modulator
15 Appendix B - Overview of the Used
Technologies
15.1 DVB-S2
Newtec M6100 delivers the best and most robust DVB-S2 performance in the market.
Refer to the DVB-S2 standard: ETSI EN 302 307.
The following table shows the Supported MODCODs and FEC:
QPSK 1/4
QPSK 1/3
QPSK 2/5
QPSK 1/2
QPSK 3/5
QPSK 2/3
QPSK 3/4
QPSK 4/5
QPSK 5/6
QPSK 8/9
QPSK 9/10
8PSK 3/5
8PSK 2/3
8PSK3/4
8PSK 5/6
8PSK 8/9
8PSK 9/10
16APSK 2/3
16APSK 3/4
16APSK 4/5
16APSK 5/6
16APSK 8/9
16APSK 9/10
32APSK 3/4
32APSK 4/5
32APSK 5/6
32APSK 8/9
32APSK 9/10
15.2 S2 Extensions
Newtec also introduces a new modulation technology that outperforms the existing DVB-S2
standard. This new technology is called S2 Extensions and when combined with CCT it delivers
gains up to 37% compared to standard DVB-S2 modulation.
The main features of the new technology are:
• Finer MODCOD granularity: there are 87 MODCODs (compared to the 28 MODCODs in
DVB-S2);
• Better MODCOD performance: FEC codes and modulations have been redesigned in order to
improve the performance of the existing DVB-S2 MODCODs;
• Optimization for linear and non-linear satellite links: Two sets of MODCODs are available:
