Features Descriptions M6100 Broadcast Satellite Modulator
12.1.2 Input Type
Select the type of input packets or frames.
• TS (Transport Stream);
• BBF (Baseband Frames).
12.1.3 Transmit
M6100 >> Modulator >> Transmit
This is the modulator output transmission.
Enable transmit when the complete configuration is done according to the system requirements.
A warning is displayed when it is not allowed to change a parameter when transmit is
enabled.
This will be the case with parameters that influence the transmitted signal and its
spectrum.
Transmit State Reason
The parameter displays why the transmission is on or off. This parameter is valuable when the
transmission is off due to an alarm. It reflects the alarm state's that are configured under transmit
control.
12.1.4 Output Frequency and Output Band
M6100 >> Modulator >> Output Frequency
Set the output frequency of the modulator. The output frequency must be in-line with the device
capabilities (L-band or IF band) and the system requirements.
Output Frequency
• L-band: 950MHz to 2150MHz;
• IF-band: 50MHz to 180MHz.
The device performs a check whether the inserted frequency is within the allowed frequency range.
