Features Descriptions M6100 Broadcast Satellite Modulator
12 Features Descriptions
12.1 Modulator
The modulator functional block is used to perform the actual modulation of the TS.
M6100> Modulator
The main parameters are:
• Mode DVB-S/DVB-S2/S2-Extensions;
• Transmit On/Off;
• Output Level;
• Output Frequency;
• Frame Type;
• Pilots;
• ModCod;
• Rate Priority;
• Symbol Rate;
• Bit Rate.
12.1.1 Modulation Mode
Select the modulation mode DVB-S, DVB-S2, S2-Extensions.
M6100> Modulator >> Mode
• DVB-S;
• DVB-S2;
• S2-Extensions.
