Data Interfaces M6100 Broadcast Satellite Modulator
11 Data Interfaces
11.1 Data Ethernet Interfaces
The data interfaces can be configured on the following location:
M6100 >> Data Interface >> Ethernet
• Data1 (This port is the top port on the back panel indicated as data1);
• Data2 (This port is the bottom port on the back panel indicated as data2);
When link redundancy is needed, Data1 and Data2 must be enabled and auto
negation must be on. To enable link redundancy, refer to section:
EthernetLinkRedundancy.onpage112
Per interface, the following information is displayed.
• Default interface name; (read only)
• Enabled (On/Off);
• MAC address;
• Auto Negotiation (On/Off);
• Advertised Speeds;
• Forced Speed;
• Link State.
• MTU (Maximum Transmission Unit)
Range: 68 - 9582
Statistics
M6100 >> Data Interface >> Statistics
This provides an overview of the traffic that is passing over the different Ethernet ports.
The following statistics are displayed:
• Input Bytes;
• Input Packets;
• Input Dropped;
• Input Errors;
• Output Bytes
• Output Packets;
• Output Dropped;
• Output Errors.
